XW4M-18D2-H1DS
Omron Electronics Components
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionPLUG,DOUBLE-ROW,RIGHT-ANGLE,TIN
- CategoryTerminal Blocks - Headers, Plugs and Sockets
-
ECAD Model
- Share
In Stock: 135
Can ship immediately
Pricing:
- 1$9.22
Quote It
Technical Details
- Series:-
- Package:Tray
- Part Status:Active
- Type:Header, Male Pins, Shrouded (4 Side)
- Number of Positions:18
- Positions Per Level:9
- Number of Levels:2
- Pitch:0.138" (3.50mm)
- Header Orientation:90°, Right Angle
- Plug Wire Entry:-
- Termination Style:Solder
- Mounting Type:Through Hole
- Current - IEC:8A
- Voltage - IEC:160 A
- Current - UL:8 V
- Voltage - UL:300 V
- Wire Gauge or Range - AWG:-
- Wire Gauge or Range - mm²:-
- Color:Black
- Operating Temperature:-40°C ~ 100°C
- Contact Mating Finish:Tin
- Features:Latches
