691343410012
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- Description7.62 MM TERMINAL BLOCK PLUG, HOR
- CategoryTerminal Blocks - Headers, Plugs and Sockets
-
ECAD Model
- Share
In Stock: 142
Can ship immediately
Pricing:
- 1$17.72
Quote It
Technical Details
- Series:WR-TBL Series 3434
- Package:Bulk
- Part Status:Active
- Type:Plug, Female Sockets
- Number of Positions:12
- Positions Per Level:12
- Number of Levels:1
- Pitch:0.300" (7.62mm)
- Header Orientation:-
- Plug Wire Entry:90°
- Termination Style:Screw - Leaf Spring, Wire Guard
- Mounting Type:Free Hanging (In-Line)
- Current - IEC:-
- Voltage - IEC:-
- Current - UL:15 A
- Voltage - UL:300 V
- Wire Gauge or Range - AWG:12-24 AWG
- Wire Gauge or Range - mm²:0.21-3.31mm²
- Color:Green
- Operating Temperature:-40°C ~ 105°C
- Contact Mating Finish:-
- Features:Mating Flange, Retention Latches (Wire Side)
