TJ0751540000G
Anytek (Amphenol Anytek)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTERM BLOCK PLUG 7POS STR 5.08MM
- CategoryTerminal Blocks - Headers, Plugs and Sockets
- Datasheet TJ0751540000G Datasheet
-
ECAD Model
- Share
In Stock: 113
Can ship immediately
Pricing:
- 1$1.18625
- 2,025$1.18625
Quote It
Technical Details
- Series:TJ
- Package:Bulk
- Part Status:Active
- Type:Plug, Female Sockets
- Number of Positions:7
- Positions Per Level:7
- Number of Levels:1
- Pitch:0.200" (5.08mm)
- Header Orientation:-
- Plug Wire Entry:180°
- Termination Style:Screw
- Mounting Type:Free Hanging (In-Line)
- Current - IEC:20A
- Voltage - IEC:300 V
- Current - UL:20 A
- Voltage - UL:300 V
- Wire Gauge or Range - AWG:12-24 AWG
- Wire Gauge or Range - mm²:0.34-2.5mm²
- Color:Green
- Operating Temperature:-40°C ~ 115°C
- Contact Mating Finish:Tin
- Features:Retention Latches (Non-Wire Side), Strain Relief
