TJ08A1020000G
Anytek (Amphenol Anytek)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTERM BLOCK PLUG 8POS STR 7.5MM
- CategoryTerminal Blocks - Headers, Plugs and Sockets
- Datasheet TJ08A1020000G Datasheet
-
ECAD Model
- Share
In Stock: 149
Can ship immediately
Pricing:
- 1$1.31222
- 3,025$1.31222
Quote It
Technical Details
- Series:TJ
- Package:Bulk
- Part Status:Active
- Type:Plug, Female Sockets
- Number of Positions:8
- Positions Per Level:8
- Number of Levels:1
- Pitch:0.295" (7.50mm)
- Header Orientation:-
- Plug Wire Entry:180°
- Termination Style:Screw
- Mounting Type:Free Hanging (In-Line)
- Current - IEC:-
- Voltage - IEC:-
- Current - UL:20 A
- Voltage - UL:300 V
- Wire Gauge or Range - AWG:12-24 AWG
- Wire Gauge or Range - mm²:-
- Color:Black
- Operating Temperature:-40°C ~ 115°C
- Contact Mating Finish:Tin
- Features:Mating Flange, Retention Latches (Non-Wire Side)
