VM0975500000G
Anytek (Amphenol Anytek)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTERM BLOCK PLUG 9POS STR 5MM
- CategoryTerminal Blocks - Headers, Plugs and Sockets
- Datasheet VM0975500000G Datasheet
-
ECAD Model
- Share
In Stock: 114
Can ship immediately
Pricing:
- 1$1.8986
- 2,040$1.8986
Quote It
Technical Details
- Series:VM
- Package:Bulk
- Part Status:Active
- Type:Plug, Female Sockets
- Number of Positions:9
- Positions Per Level:9
- Number of Levels:1
- Pitch:0.197" (5.00mm)
- Header Orientation:-
- Plug Wire Entry:180°
- Termination Style:Screw - Pressure Clip
- Mounting Type:Free Hanging (In-Line)
- Current - IEC:-
- Voltage - IEC:-
- Current - UL:20 A
- Voltage - UL:300 V
- Wire Gauge or Range - AWG:12-22 AWG
- Wire Gauge or Range - mm²:0.34-2.5mm²
- Color:Green
- Operating Temperature:-40°C ~ 115°C
- Contact Mating Finish:Tin
- Features:Retention Latches (Non-Wire Side)
