2350397-8
TE Connectivity AMP Connectors- Lifecycle status Active
- RoHS RoHS Compliant
- Description8 POS SPRING TB PLUG PITCH 5.00
- CategoryTerminal Blocks - Headers, Plugs and Sockets
-
ECAD Model
- Share
In Stock: 106
Can ship immediately
Pricing:
- 1$2.13978
Quote It
Technical Details
- Series:TB, Buchanan
- Package:Bulk
- Part Status:Active
- Type:Plug, Female Sockets
- Number of Positions:8
- Positions Per Level:8
- Number of Levels:1
- Pitch:0.197" (5.00mm)
- Header Orientation:-
- Plug Wire Entry:180°
- Termination Style:Screwless - Leg Spring, Push-In Spring
- Mounting Type:Free Hanging (In-Line)
- Current - IEC:-
- Voltage - IEC:-
- Current - UL:16 A
- Voltage - UL:300 V
- Wire Gauge or Range - AWG:12-26 AWG
- Wire Gauge or Range - mm²:0.13-3.31mm²
- Color:Green
- Operating Temperature:-40°C ~ 105°C
- Contact Mating Finish:Tin
- Features:Push Button Actuated, Retention Latches (Non-Wire Side)
