1643380000
Weidmuller- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTERM BLOCK HDR 7POS 135DEG 3.5MM
- CategoryTerminal Blocks - Headers, Plugs and Sockets
- Datasheet 1643380000 Datasheet
-
ECAD Model
- Share
In Stock: 126
Can ship immediately
Pricing:
- 1$2.39204
- 54$2.28574
Quote It
Technical Details
- Series:Omnimate SL
- Package:Bulk
- Part Status:Active
- Type:Header, Male Pins, Shrouded (4 Side)
- Number of Positions:7
- Positions Per Level:7
- Number of Levels:1
- Pitch:0.138" (3.50mm)
- Header Orientation:135°
- Plug Wire Entry:-
- Termination Style:Solder
- Mounting Type:Through Hole
- Current - IEC:15A
- Voltage - IEC:320 V
- Current - UL:10 A
- Voltage - UL:300 V
- Wire Gauge or Range - AWG:-
- Wire Gauge or Range - mm²:-
- Color:Orange
- Operating Temperature:-50°C ~ 100°C
- Contact Mating Finish:Tin
- Features:Mating Flange
