TS21718A0000G
Anytek (Amphenol Anytek)- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTERM BLOCK PLUG 21POS 90DEG 5MM
- CategoryTerminal Blocks - Headers, Plugs and Sockets
- Datasheet TS21718A0000G Datasheet
-
ECAD Model
- Share
In Stock: 174
Can ship immediately
Pricing:
- 1$2.80214
- 3,000$2.80214
Quote It
Technical Details
- Series:TS
- Package:Bulk
- Part Status:Active
- Type:Plug, Female Sockets
- Number of Positions:21
- Positions Per Level:21
- Number of Levels:1
- Pitch:0.197" (5.00mm)
- Header Orientation:-
- Plug Wire Entry:90°
- Termination Style:Screw - Leaf Spring, Wire Guard
- Mounting Type:Free Hanging (In-Line)
- Current - IEC:-
- Voltage - IEC:-
- Current - UL:15 A
- Voltage - UL:300 V
- Wire Gauge or Range - AWG:12-24 AWG
- Wire Gauge or Range - mm²:0.34-2.5mm²
- Color:Gray
- Operating Temperature:-40°C ~ 115°C
- Contact Mating Finish:Tin
- Features:Retention Latches (Wire Side)
