0395281022
Woodhead - Molex- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTERM BLOCK HDR 22POS 90DEG 5MM
- CategoryTerminal Blocks - Headers, Plugs and Sockets
- Datasheet 0395281022 Datasheet
-
ECAD Model
- Share
In Stock: 188
Can ship immediately
Pricing:
- 1$3.27
- 576$3.27
Quote It
Technical Details
- Series:Eurostyle ESE 39528
- Package:Bulk
- Part Status:Active
- Type:Header, Male Pins, Shrouded (4 Side)
- Number of Positions:22
- Positions Per Level:11
- Number of Levels:2
- Pitch:0.197" (5.00mm)
- Header Orientation:90°, Right Angle
- Plug Wire Entry:-
- Termination Style:Solder
- Mounting Type:Through Hole
- Current - IEC:-
- Voltage - IEC:-
- Current - UL:15 A
- Voltage - UL:300 V
- Wire Gauge or Range - AWG:-
- Wire Gauge or Range - mm²:-
- Color:Black
- Operating Temperature:-40°C ~ 105°C
- Contact Mating Finish:Tin
- Features:-
