ASP0251104
RIA Connect / METZ CONNECT- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSPRING CLAMP TERMINAL BLOCK, PLU
- CategoryTerminal Blocks - Headers, Plugs and Sockets
-
ECAD Model
- Share
In Stock: 184
Can ship immediately
Pricing:
- 1$3.72638
- 100$3.72638
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Type:Plug for Unshrouded Header
- Number of Positions:11
- Positions Per Level:11
- Number of Levels:1
- Pitch:0.197" (5.00mm)
- Header Orientation:-
- Plug Wire Entry:90°
- Termination Style:Screwless - Spring Cage, Tension Clamp
- Mounting Type:Free Hanging (In-Line)
- Current - IEC:-
- Voltage - IEC:-
- Current - UL:8 A
- Voltage - UL:300 V
- Wire Gauge or Range - AWG:16-28 AWG
- Wire Gauge or Range - mm²:0.08-1.5mm²
- Color:Gray
- Operating Temperature:-40°C ~ 105°C
- Contact Mating Finish:Tin
- Features:Lever Actuated
