1728340000
Weidmuller
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTERM BLOCK HDR 12POS 90DEG 3.5MM
- CategoryTerminal Blocks - Headers, Plugs and Sockets
-
ECAD Model
- Share
In Stock: 106
Can ship immediately
Pricing:
- 1$4.16202
- 10$3.17204
- 25$2.97086
- 50$2.64082
- 100$2.58344
- 250$2.38248
- 500$2.15285
- 1,000$1.90886
Quote It
Technical Details
- Series:Omnimate S2L
- Package:Bulk
- Part Status:Active
- Type:Header, Male Pins, Shrouded (2 Side)
- Number of Positions:12
- Positions Per Level:6
- Number of Levels:2
- Pitch:0.138" (3.50mm)
- Header Orientation:90°, Right Angle
- Plug Wire Entry:-
- Termination Style:Solder
- Mounting Type:Through Hole
- Current - IEC:7.5A
- Voltage - IEC:100 V
- Current - UL:10 A
- Voltage - UL:150 V
- Wire Gauge or Range - AWG:-
- Wire Gauge or Range - mm²:-
- Color:Black
- Operating Temperature:-20°C ~ 100°C
- Contact Mating Finish:Tin
- Features:-
