1909427
Phoenix Contact
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTERM BLOCK PLUG 4POS STR 5MM
- CategoryTerminal Blocks - Headers, Plugs and Sockets
- Datasheet 1909427 Datasheet
-
ECAD Model
- Share
In Stock: 171
Can ship immediately
Pricing:
- 1$4.71
- 50$4.71
Quote It
Technical Details
- Series:COMBICON FKCT
- Package:Bulk
- Part Status:Active
- Type:Plug, Female Sockets
- Number of Positions:4
- Positions Per Level:4
- Number of Levels:1
- Pitch:0.197" (5.00mm)
- Header Orientation:-
- Plug Wire Entry:180°
- Termination Style:Screwless - Leg Spring, Push-In Spring
- Mounting Type:Free Hanging (In-Line)
- Current - IEC:12A
- Voltage - IEC:630 V
- Current - UL:10 A
- Voltage - UL:300 V
- Wire Gauge or Range - AWG:12-26 AWG
- Wire Gauge or Range - mm²:0.2-2.5mm²
- Color:Green
- Operating Temperature:-
- Contact Mating Finish:Tin
- Features:Mating Flange
