NF2050510000G

Technical Details

• Series:NF
• Package:Bulk
• Part Status:Active
• Type:Plug, Female Sockets
• Number of Positions:20 (Mate), 40 (Input)
• Positions Per Level:20 (Mate), 40 (Input)
• Number of Levels:1 (Mate), 2 (Input)
• Pitch:0.200" (5.08mm)
• Header Orientation:-
• Plug Wire Entry:180°
• Termination Style:Screwless - Leg Spring, Push-In Spring

• Mounting Type:Free Hanging (In-Line)
• Current - IEC:-
• Voltage - IEC:-
• Current - UL:8 A
• Voltage - UL:300 V
• Wire Gauge or Range - AWG:12-26 AWG
• Wire Gauge or Range - mm²:-
• Color:Green
• Operating Temperature:-40°C ~ 115°C
• Contact Mating Finish:Tin
• Features:Mating Flange, Retention Latches (Non-Wire Side)
