DCP4N051507GD2KSSD
WIMA
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP FILM 15UF 10% 900VDC RADIAL
- CategoryFilm Capacitors
-
ECAD Model
- Share
In Stock: 190
Can ship immediately
Pricing:
- 1$6.75
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Capacitance:15 µF
- Tolerance:±10%
- Voltage Rating - AC:-
- Voltage Rating - DC:900V
- Dielectric Material:Polypropylene (PP), Metallized
- ESR (Equivalent Series Resistance):5.8 mOhms
- Operating Temperature:-55°C ~ 105°C
- Mounting Type:Through Hole
- Package / Case:Radial
- Size / Dimension:1.634" L x 0.787" W (41.50mm x 20.00mm)
- Height - Seated (Max):1.555" (39.50mm)
- Termination:PC Pins
- Lead Spacing:1.476" (37.50mm)
- Applications:Automotive; DC Link, DC Filtering
- Ratings:AEC-Q200
- Features:-
