PMB2124200KVR
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- Description1200V,2UF,10 PERCENT, LUG MOUNT
- CategoryFilm Capacitors
-
ECAD Model
- Share
In Stock: 308
Can ship immediately
Pricing:
- 1$18.44
Quote It
Technical Details
- Series:PMB
- Package:Bulk
- Part Status:Active
- Capacitance:2 µF
- Tolerance:±10%
- Voltage Rating - AC:630V
- Voltage Rating - DC:1200V (1.2kV)
- Dielectric Material:Polypropylene (PP), Metallized
- ESR (Equivalent Series Resistance):2.4 mOhms
- Operating Temperature:-40°C ~ 85°C
- Mounting Type:Chassis Mount
- Package / Case:Rectangular Box
- Size / Dimension:2.264" L x 1.181" W (57.50mm x 30.00mm)
- Height - Seated (Max):1.772" (45.00mm)
- Termination:Screw Terminals
- Lead Spacing:-
- Applications:High Frequency, Switching; High Pulse, DV/DT; Snubber
- Ratings:-
- Features:-
