SMDB15LCCTR
SMC Diode Solutions
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTVS DIODE 15V 24V 8SO
- CategoryTVS - Diodes
- Datasheet SMDB15LCCTR Datasheet
-
ECAD Model
- Share
In Stock: 127
Can ship immediately
Pricing:
- 1$0.64
- 2,500$0.64
- 5,000$0.60445
- 12,500$0.58665
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Zener
- Unidirectional Channels:-
- Bidirectional Channels:4
- Voltage - Reverse Standoff (Typ):15V (Max)
- Voltage - Breakdown (Min):16.7V
- Voltage - Clamping (Max) @ Ipp:24V
- Current - Peak Pulse (10/1000µs):1A
- Power - Peak Pulse:500W
- Power Line Protection:No
- Applications:General Purpose
- Capacitance @ Frequency:15pF @ 1MHz
- Operating Temperature:-55°C ~ 125°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package:8-SO
