SZESD7008MUTAG
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTVS DIODE 5V 10V 18UDFN
- CategoryTVS - Diodes
- Datasheet SZESD7008MUTAG Datasheet
-
ECAD Model
- Share
In Stock: 119,857,104
Can ship immediately
Pricing:
- 1$0.86
- 3,000$0.86
- 6,000$0.8007
- 15,000$0.79081
Quote It
Technical Details
- Series:Automotive, AEC-Q101
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Zener
- Unidirectional Channels:8
- Bidirectional Channels:-
- Voltage - Reverse Standoff (Typ):5V (Max)
- Voltage - Breakdown (Min):5.5V
- Voltage - Clamping (Max) @ Ipp:10V
- Current - Peak Pulse (10/1000µs):1A (8/20µs)
- Power - Peak Pulse:-
- Power Line Protection:No
- Applications:Automotive, HDMI
- Capacitance @ Frequency:0.12pF @ 1MHz
- Operating Temperature:-55°C ~ 125°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:18-UFDFN Exposed Pad
- Supplier Device Package:18-UDFN (5.5x1.5)
