SMAJ90A-E3/61
Vishay General Semiconductor – Diodes Division
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTVS DIODE 90V 146V DO214AC
- CategoryTVS - Diodes
- Datasheet SMAJ90A-E3/61 Datasheet
-
ECAD Model
- Share
In Stock: 413
Can ship immediately
Pricing:
- 1$0.4
- 1,800$0.11972
- 3,600$0.10893
- 5,400$0.10354
- 12,600$0.09545
- 45,000$0.09005
Quote It
Technical Details
- Series:TransZorb®
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Zener
- Unidirectional Channels:1
- Bidirectional Channels:-
- Voltage - Reverse Standoff (Typ):90V
- Voltage - Breakdown (Min):100V
- Voltage - Clamping (Max) @ Ipp:146V
- Current - Peak Pulse (10/1000µs):2.1A
- Power - Peak Pulse:300W
- Power Line Protection:No
- Applications:General Purpose
- Capacitance @ Frequency:-
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:DO-214AC, SMA
- Supplier Device Package:DO-214AC (SMA)
