SMBJ170A-E3/52
Vishay General Semiconductor – Diodes Division
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTVS DIODE 170V 275V DO214AA
- CategoryTVS - Diodes
- Datasheet SMBJ170A-E3/52 Datasheet
-
ECAD Model
- Share
In Stock: 801
Can ship immediately
Pricing:
- 1$0.45
- 3,000$0.12935
Quote It
Technical Details
- Series:TransZorb®
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Zener
- Unidirectional Channels:1
- Bidirectional Channels:-
- Voltage - Reverse Standoff (Typ):170V
- Voltage - Breakdown (Min):189V
- Voltage - Clamping (Max) @ Ipp:275V
- Current - Peak Pulse (10/1000µs):2.2A
- Power - Peak Pulse:600W
- Power Line Protection:No
- Applications:General Purpose
- Capacitance @ Frequency:-
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:DO-214AA, SMB
- Supplier Device Package:DO-214AA (SMBJ)
