TPSMB16A
Wickmann / Littelfuse
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTVS DIODE 13.6V 22.5V DO214AA
- CategoryTVS - Diodes
- Datasheet TPSMB16A Datasheet
-
ECAD Model
- Share
In Stock: 177
Can ship immediately
Pricing:
- 1$0.55
- 3,000$0.55
- 6,000$0.51715
- 15,000$0.48428
- 30,000$0.4788
Quote It
Technical Details
- Series:Automotive, AEC-Q101, TPSMB
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Zener
- Unidirectional Channels:1
- Bidirectional Channels:-
- Voltage - Reverse Standoff (Typ):13.6V
- Voltage - Breakdown (Min):15.2V
- Voltage - Clamping (Max) @ Ipp:22.5V
- Current - Peak Pulse (10/1000µs):27.1A
- Power - Peak Pulse:600W
- Power Line Protection:No
- Applications:Automotive
- Capacitance @ Frequency:-
- Operating Temperature:-65°C ~ 175°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:DO-214AA, SMB
- Supplier Device Package:DO-214AA (SMBJ)
