SZTVS4201MR6T1G
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTVS DIODE 5V 12V 6TSOP
- CategoryTVS - Diodes
- Datasheet SZTVS4201MR6T1G Datasheet
-
ECAD Model
- Share
In Stock: 806
Can ship immediately
Pricing:
- 1$0.58
- 3,000$0.18356
- 6,000$0.17172
- 15,000$0.15988
- 30,000$0.1579
Quote It
Technical Details
- Series:Automotive, AEC-Q101
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Steering (Rail to Rail)
- Unidirectional Channels:4
- Bidirectional Channels:-
- Voltage - Reverse Standoff (Typ):5V (Max)
- Voltage - Breakdown (Min):6V
- Voltage - Clamping (Max) @ Ipp:12V
- Current - Peak Pulse (10/1000µs):25A (8/20µs)
- Power - Peak Pulse:500W
- Power Line Protection:Yes
- Applications:Automotive
- Capacitance @ Frequency:3pF @ 1MHz
- Operating Temperature:-40°C ~ 125°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:SOT-23-6 Thin, TSOT-23-6
- Supplier Device Package:6-TSOP
