SMBJ26CA R5G
TSC (Taiwan Semiconductor)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTVS DIODE 26V 42.1V DO214AA
- CategoryTVS - Diodes
- Datasheet SMBJ26CA R5G Datasheet
-
ECAD Model
- Share
In Stock: 334
Can ship immediately
Pricing:
- 1$0.62
- 850$0.28185
- 1,700$0.25549
- 2,550$0.23572
- 5,950$0.22254
- 21,250$0.20935
Quote It
Technical Details
- Series:SMBJ
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Zener
- Unidirectional Channels:-
- Bidirectional Channels:1
- Voltage - Reverse Standoff (Typ):26V
- Voltage - Breakdown (Min):28.9V
- Voltage - Clamping (Max) @ Ipp:42.1V
- Current - Peak Pulse (10/1000µs):14.9A
- Power - Peak Pulse:600W
- Power Line Protection:No
- Applications:General Purpose
- Capacitance @ Frequency:-
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:DO-214AA, SMB
- Supplier Device Package:DO-214AA (SMB)
