SMBG24A-E3/52
Vishay General Semiconductor – Diodes Division
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTVS DIODE 24V 38.9V DO215AA
- CategoryTVS - Diodes
- Datasheet SMBG24A-E3/52 Datasheet
-
ECAD Model
- Share
In Stock: 120
Can ship immediately
Pricing:
- 1$0.63
- 750$0.34672
- 1,500$0.27505
- 2,250$0.25355
- 5,250$0.23922
- 18,750$0.22489
Quote It
Technical Details
- Series:TransZorb®
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Zener
- Unidirectional Channels:1
- Bidirectional Channels:-
- Voltage - Reverse Standoff (Typ):24V
- Voltage - Breakdown (Min):26.7V
- Voltage - Clamping (Max) @ Ipp:38.9V
- Current - Peak Pulse (10/1000µs):15.4A
- Power - Peak Pulse:600W
- Power Line Protection:No
- Applications:General Purpose
- Capacitance @ Frequency:-
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:DO-215AA, SMB Gull Wing
- Supplier Device Package:DO-215AA (SMBG)
