1SMB16AT3
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTRANS VOLTAGE SUPPRESSOR DIODE
- CategoryTVS - Diodes
- Datasheet 1SMB16AT3 Datasheet
-
ECAD Model
- Share
In Stock: 143
Can ship immediately
Pricing:
- 1$0.12
- 2,500$0.12
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Obsolete
- Type:Zener
- Unidirectional Channels:1
- Bidirectional Channels:-
- Voltage - Reverse Standoff (Typ):16V
- Voltage - Breakdown (Min):17.8V
- Voltage - Clamping (Max) @ Ipp:26V
- Current - Peak Pulse (10/1000µs):23.1A
- Power - Peak Pulse:600W
- Power Line Protection:No
- Applications:General Purpose
- Capacitance @ Frequency:965pF @ 1MHz
- Operating Temperature:-65°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:DO-214AA, SMB
- Supplier Device Package:SMB
