1KSMB9.1A
Wickmann / Littelfuse
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTVS DIODE 7.78V 13.4V DO214AA
- CategoryTVS - Diodes
- Datasheet 1KSMB9.1A Datasheet
-
ECAD Model
- Share
In Stock: 145
Can ship immediately
Pricing:
- 1$0.25323
- 3,000$0.25323
Quote It
Technical Details
- Series:1KSMB
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Zener
- Unidirectional Channels:1
- Bidirectional Channels:-
- Voltage - Reverse Standoff (Typ):7.78V
- Voltage - Breakdown (Min):8.65V
- Voltage - Clamping (Max) @ Ipp:13.4V
- Current - Peak Pulse (10/1000µs):74.6A
- Power - Peak Pulse:1000W (1kW)
- Power Line Protection:No
- Applications:General Purpose
- Capacitance @ Frequency:-
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:DO-214AA, SMB
- Supplier Device Package:DO-214AA (SMBJ)
