SMBJ54A-HR
Wickmann / Littelfuse
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTVS DIODE 54V 87.1V DO214AA
- CategoryTVS - Diodes
- Datasheet SMBJ54A-HR Datasheet
-
ECAD Model
- Share
In Stock: 161
Can ship immediately
Pricing:
- 1$5.8968
- 3,000$5.8968
Quote It
Technical Details
- Series:SMBJ-HR
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Zener
- Unidirectional Channels:1
- Bidirectional Channels:-
- Voltage - Reverse Standoff (Typ):54V
- Voltage - Breakdown (Min):60V
- Voltage - Clamping (Max) @ Ipp:87.1V
- Current - Peak Pulse (10/1000µs):6.9A
- Power - Peak Pulse:600W
- Power Line Protection:No
- Applications:General Purpose
- Capacitance @ Frequency:-
- Operating Temperature:-65°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:DO-214AA, SMB
- Supplier Device Package:DO-214AA (SMBJ)
