D5V0Q1B2CSP-7
Zetex Semiconductors (Diodes Inc.)- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTVS DIODE 5.5V 8.4V DSN0603-2
- CategoryTVS - Diodes
- Datasheet D5V0Q1B2CSP-7 Datasheet
-
ECAD Model
- Share
In Stock: 109
Can ship immediately
Pricing:
- 1$0.05049
- 10,000$0.05049
Quote It
Technical Details
- Series:Automotive, AEC-Q101
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Zener
- Unidirectional Channels:-
- Bidirectional Channels:1
- Voltage - Reverse Standoff (Typ):5.5V (Max)
- Voltage - Breakdown (Min):6V
- Voltage - Clamping (Max) @ Ipp:8.4V (Typ)
- Current - Peak Pulse (10/1000µs):3A (8/20µs)
- Power - Peak Pulse:-
- Power Line Protection:No
- Applications:Automotive
- Capacitance @ Frequency:5.5pF @ 1MHz
- Operating Temperature:-65°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:0201 (0603 Metric)
- Supplier Device Package:X2-DSN0603-2
