In Stock: 149

Can ship immediately

Pricing:
  • 1$0.10187
  • 50,000$0.10187

Quote It

Technical Details

  • Series:-
  • Package:Tape & Reel (TR)
  • Part Status:Active
  • Type:Zener
  • Unidirectional Channels:1
  • Bidirectional Channels:-
  • Voltage - Reverse Standoff (Typ):12V
  • Voltage - Breakdown (Min):13.3V
  • Voltage - Clamping (Max) @ Ipp:19.9V



  • Current - Peak Pulse (10/1000µs):10.1A
  • Power - Peak Pulse:200W
  • Power Line Protection:No
  • Applications:General Purpose
  • Capacitance @ Frequency:483pF @ 1MHz
  • Operating Temperature:-65°C ~ 175°C (TJ)
  • Mounting Type:Surface Mount
  • Package / Case:DO-219AB
  • Supplier Device Package:SMF (DO-219AB)
