SMA4S22AH
TSC (Taiwan Semiconductor)
- Lifecycle status Active
- RoHS RoHS Compliant
- Description400W, 10V - 70V, SMD TVS PG STRU
- CategoryTVS - Diodes
-
ECAD Model
- Share
In Stock: 147
Can ship immediately
Pricing:
- 1$0.10457
- 14,000$0.10457
Quote It
Technical Details
- Series:Automotive, AEC-Q101
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Zener
- Unidirectional Channels:1
- Bidirectional Channels:-
- Voltage - Reverse Standoff (Typ):22V
- Voltage - Breakdown (Min):24.6V
- Voltage - Clamping (Max) @ Ipp:35.7V
- Current - Peak Pulse (10/1000µs):11.2A
- Power - Peak Pulse:400W
- Power Line Protection:No
- Applications:Automotive
- Capacitance @ Frequency:-
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:SOD-128
- Supplier Device Package:SOD-128
