SMA5J8.5CA-E3/5A
Vishay General Semiconductor – Diodes Division
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTVS DIODE 8.5V 14.4V DO214AC
- CategoryTVS - Diodes
- Datasheet SMA5J8.5CA-E3/5A Datasheet
-
ECAD Model
- Share
In Stock: 166
Can ship immediately
Pricing:
- 1$0.15063
- 7,500$0.15063
Quote It
Technical Details
- Series:TransZorb®
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Zener
- Unidirectional Channels:-
- Bidirectional Channels:1
- Voltage - Reverse Standoff (Typ):8.5V
- Voltage - Breakdown (Min):9.44V
- Voltage - Clamping (Max) @ Ipp:14.4V
- Current - Peak Pulse (10/1000µs):34.7A
- Power - Peak Pulse:500W
- Power Line Protection:No
- Applications:General Purpose
- Capacitance @ Frequency:-
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:DO-214AC, SMA
- Supplier Device Package:DO-214AC (SMA)
