SMBJ120CA M4G
TSC (Taiwan Semiconductor)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTVS DIODE 120V 193V DO214AA
- CategoryTVS - Diodes
- Datasheet SMBJ120CA M4G Datasheet
-
ECAD Model
- Share
In Stock: 122
Can ship immediately
Pricing:
- 1$0.15775
- 3,000$0.15775
Quote It
Technical Details
- Series:SMBJ
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Zener
- Unidirectional Channels:-
- Bidirectional Channels:1
- Voltage - Reverse Standoff (Typ):120V
- Voltage - Breakdown (Min):133V
- Voltage - Clamping (Max) @ Ipp:193V
- Current - Peak Pulse (10/1000µs):3.2A
- Power - Peak Pulse:600W
- Power Line Protection:No
- Applications:General Purpose
- Capacitance @ Frequency:-
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:DO-214AA, SMB
- Supplier Device Package:DO-214AA (SMB)
