In Stock: 118

Can ship immediately

Pricing:
  • 1$0.16709
  • 4,000$0.16709

Quote It

Technical Details

  • Series:Automotive, AEC-Q101, SMAJ
  • Package:Tape & Reel (TR)
  • Part Status:Active
  • Type:Zener
  • Unidirectional Channels:1
  • Bidirectional Channels:-
  • Voltage - Reverse Standoff (Typ):15V
  • Voltage - Breakdown (Min):16.7V
  • Voltage - Clamping (Max) @ Ipp:24.4V



  • Current - Peak Pulse (10/1000µs):16.4A
  • Power - Peak Pulse:400W
  • Power Line Protection:No
  • Applications:Automotive
  • Capacitance @ Frequency:-
  • Operating Temperature:-55°C ~ 150°C (TJ)
  • Mounting Type:Surface Mount
  • Package / Case:DO-214AC, SMA
  • Supplier Device Package:SMA (DO-214AC)
