SMBJ90A R5G
TSC (Taiwan Semiconductor)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTVS DIODE 90V 146V DO214AA
- CategoryTVS - Diodes
- Datasheet SMBJ90A R5G Datasheet
-
ECAD Model
- Share
In Stock: 185
Can ship immediately
Pricing:
- 1$0.17255
- 1,700$0.17255
Quote It
Technical Details
- Series:SMBJ
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Zener
- Unidirectional Channels:1
- Bidirectional Channels:-
- Voltage - Reverse Standoff (Typ):90V
- Voltage - Breakdown (Min):100V
- Voltage - Clamping (Max) @ Ipp:146V
- Current - Peak Pulse (10/1000µs):4.3A
- Power - Peak Pulse:600W
- Power Line Protection:No
- Applications:General Purpose
- Capacitance @ Frequency:-
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:DO-214AA, SMB
- Supplier Device Package:DO-214AA (SMB)
