SZSL15T1G
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTVS DIODE 15V 30V SOT23-3
- CategoryTVS - Diodes
- Datasheet SZSL15T1G Datasheet
-
ECAD Model
- Share
In Stock: 78,137
Can ship immediately
Pricing:
- 1$0.18755
- 3,000$0.18755
Quote It
Technical Details
- Series:Automotive, AEC-Q101
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Zener
- Unidirectional Channels:1
- Bidirectional Channels:-
- Voltage - Reverse Standoff (Typ):15V
- Voltage - Breakdown (Min):16.7V
- Voltage - Clamping (Max) @ Ipp:30V
- Current - Peak Pulse (10/1000µs):5A (8/20µs)
- Power - Peak Pulse:300W
- Power Line Protection:No
- Applications:Automotive
- Capacitance @ Frequency:3.5pF @ 1MHz
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:TO-236-3, SC-59, SOT-23-3
- Supplier Device Package:SOT-23-3 (TO-236)
