ESD1L001W1T2G
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTVS DIODE 5V 30V SC70-6
- CategoryTVS - Diodes
- Datasheet ESD1L001W1T2G Datasheet
-
ECAD Model
- Share
In Stock: 117,176
Can ship immediately
Pricing:
- 1$0.20102
- 3,000$0.20102
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Zener
- Unidirectional Channels:4
- Bidirectional Channels:-
- Voltage - Reverse Standoff (Typ):5V
- Voltage - Breakdown (Min):16.5V
- Voltage - Clamping (Max) @ Ipp:30V (Typ)
- Current - Peak Pulse (10/1000µs):-
- Power - Peak Pulse:-
- Power Line Protection:No
- Applications:HDMI, USB
- Capacitance @ Frequency:0.3pF @ 1MHz
- Operating Temperature:-55°C ~ 125°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:6-TSSOP, SC-88, SOT-363
- Supplier Device Package:SC-70-6
