VTVS14GSMF-M3-18
Vishay General Semiconductor – Diodes Division
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTVS DIODE 13.8V 22.2V DO219AB
- CategoryTVS - Diodes
- Datasheet VTVS14GSMF-M3-18 Datasheet
-
ECAD Model
- Share
In Stock: 106
Can ship immediately
Pricing:
- 1$0.2338
- 50,000$0.2338
Quote It
Technical Details
- Series:TransZorb®
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Zener
- Unidirectional Channels:1
- Bidirectional Channels:-
- Voltage - Reverse Standoff (Typ):13.8V
- Voltage - Breakdown (Min):15.88V
- Voltage - Clamping (Max) @ Ipp:22.2V
- Current - Peak Pulse (10/1000µs):17.67A
- Power - Peak Pulse:400W
- Power Line Protection:No
- Applications:General Purpose
- Capacitance @ Frequency:752pF @ 1MHz
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:DO-219AB
- Supplier Device Package:DO-219AB (SMF)
