SMCJ14CA-Q
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTVS DIODE 14V 23.2V SMC
- CategoryTVS - Diodes
- Datasheet SMCJ14CA-Q Datasheet
-
ECAD Model
- Share
In Stock: 160
Can ship immediately
Pricing:
- 1$0.3
- 12,000$0.3
Quote It
Technical Details
- Series:Automotive, AEC-Q101, SMCJ
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Zener
- Unidirectional Channels:-
- Bidirectional Channels:1
- Voltage - Reverse Standoff (Typ):14V
- Voltage - Breakdown (Min):15.6V
- Voltage - Clamping (Max) @ Ipp:23.2V
- Current - Peak Pulse (10/1000µs):64.7A
- Power - Peak Pulse:1500W (1.5kW)
- Power Line Protection:No
- Applications:Automotive
- Capacitance @ Frequency:-
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:DO-214AB, SMC
- Supplier Device Package:SMC (DO-214AB)
