In Stock: 131

Can ship immediately

Pricing:
  • 1$0.3674
  • 3,200$0.3674

Quote It

Technical Details

  • Series:Automotive, AEC-Q101, TransZorb®
  • Package:Tape & Reel (TR)
  • Part Status:Active
  • Type:Zener
  • Unidirectional Channels:1
  • Bidirectional Channels:-
  • Voltage - Reverse Standoff (Typ):6.5V
  • Voltage - Breakdown (Min):7.22V
  • Voltage - Clamping (Max) @ Ipp:11.2V



  • Current - Peak Pulse (10/1000µs):53.6A
  • Power - Peak Pulse:600W
  • Power Line Protection:No
  • Applications:Automotive
  • Capacitance @ Frequency:-
  • Operating Temperature:-55°C ~ 150°C (TJ)
  • Mounting Type:Surface Mount
  • Package / Case:DO-215AA, SMB Gull Wing
  • Supplier Device Package:DO-215AA (SMBG)
