SMCJ85A V7G
TSC (Taiwan Semiconductor)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTVS DIODE 85V 137V DO214AB
- CategoryTVS - Diodes
- Datasheet SMCJ85A V7G Datasheet
-
ECAD Model
- Share
In Stock: 183
Can ship immediately
Pricing:
- 1$0.37048
- 1,700$0.23123
Quote It
Technical Details
- Series:SMCJ
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Zener
- Unidirectional Channels:1
- Bidirectional Channels:-
- Voltage - Reverse Standoff (Typ):85V
- Voltage - Breakdown (Min):94.4V
- Voltage - Clamping (Max) @ Ipp:137V
- Current - Peak Pulse (10/1000µs):11.5A
- Power - Peak Pulse:1500W (1.5kW)
- Power Line Protection:No
- Applications:Telecom
- Capacitance @ Frequency:-
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:DO-214AB, SMC
- Supplier Device Package:DO-214AB (SMC)
