5KP22AE3/TR13
Microchip Technology- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTVS DIODE 22V 35.5V P600
- CategoryTVS - Diodes
- Datasheet 5KP22AE3/TR13 Datasheet
-
ECAD Model
- Share
In Stock: 156
Can ship immediately
Pricing:
- 1$1.421
- 500$1.421
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Zener
- Unidirectional Channels:1
- Bidirectional Channels:-
- Voltage - Reverse Standoff (Typ):22V
- Voltage - Breakdown (Min):24.4V
- Voltage - Clamping (Max) @ Ipp:35.5V
- Current - Peak Pulse (10/1000µs):141A
- Power - Peak Pulse:5000W (5kW)
- Power Line Protection:No
- Applications:General Purpose
- Capacitance @ Frequency:-
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Through Hole
- Package / Case:P600, Axial
- Supplier Device Package:P600
Related Products
TVS DIODE 90V 146V P600
- 1: $1.42100
- 500: $1.42100
DIO TVS VWM 28V 7KW UNIDIR SM8SF
- 1: $1.42500
- 2250: $1.42500
DIO TVS VWM 30V 7KW UNIDIR SM8SF
- 1: $1.42500
- 2250: $1.42500
DIO TVS VWM 33V 7KW UNIDIR SM8SF
- 1: $1.42500
- 2250: $1.42500
DIO TVS VWM 36V 7KW UNIDIR SM8SF
