In Stock: 196

Can ship immediately

Pricing:
  • 1$2.36212
  • 750$2.33932

Quote It

Technical Details

  • Series:Automotive, AEC-Q101, PAR®
  • Package:Tape & Reel (TR)
  • Part Status:Active
  • Type:Zener
  • Unidirectional Channels:1
  • Bidirectional Channels:-
  • Voltage - Reverse Standoff (Typ):22V
  • Voltage - Breakdown (Min):24.4V
  • Voltage - Clamping (Max) @ Ipp:35.5V



  • Current - Peak Pulse (10/1000µs):130A
  • Power - Peak Pulse:4600W (4.6kW)
  • Power Line Protection:No
  • Applications:Automotive
  • Capacitance @ Frequency:-
  • Operating Temperature:-55°C ~ 175°C (TJ)
  • Mounting Type:Surface Mount
  • Package / Case:DO-218AB
  • Supplier Device Package:DO-218AB
