In Stock: 144

Can ship immediately

Pricing:
  • 1$20.25
  • 100$20.25

Quote It

Technical Details

  • Series:Military, MIL-PRF-19500
  • Package:Bulk
  • Part Status:Active
  • Type:Zener
  • Unidirectional Channels:1
  • Bidirectional Channels:-
  • Voltage - Reverse Standoff (Typ):20V
  • Voltage - Breakdown (Min):22.2V
  • Voltage - Clamping (Max) @ Ipp:32.4V



  • Current - Peak Pulse (10/1000µs):18.5A
  • Power - Peak Pulse:600W
  • Power Line Protection:No
  • Applications:General Purpose
  • Capacitance @ Frequency:-
  • Operating Temperature:-65°C ~ 150°C (TJ)
  • Mounting Type:Surface Mount
  • Package / Case:DO-214AA, SMB
  • Supplier Device Package:SMBJ (DO-214AA)
