ESD6116
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTVS DIODE 20V 4WLCSP
- CategoryTVS - Diodes
- Datasheet ESD6116 Datasheet
-
ECAD Model
- Share
In Stock: 156
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:ASIP™
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- Type:Zener
- Unidirectional Channels:1
- Bidirectional Channels:-
- Voltage - Reverse Standoff (Typ):-
- Voltage - Breakdown (Min):16V
- Voltage - Clamping (Max) @ Ipp:20V
- Current - Peak Pulse (10/1000µs):1A (8/20µs)
- Power - Peak Pulse:-
- Power Line Protection:No
- Applications:General Purpose
- Capacitance @ Frequency:-
- Operating Temperature:-30°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:4-XFBGA, WLCSP
- Supplier Device Package:4-WLCSP (0.8x0.8)
