AOZ8304ADI-02

Technical Details

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• Type:Steering (Rail to Rail)
• Unidirectional Channels:4
• Bidirectional Channels:-
• Voltage - Reverse Standoff (Typ):3.3V (Max)
• Voltage - Breakdown (Min):3.5V
• Voltage - Clamping (Max) @ Ipp:10V

• Current - Peak Pulse (10/1000µs):25A (8/20µs)
• Power - Peak Pulse:350W
• Power Line Protection:Yes
• Applications:Ethernet, Telecom
• Capacitance @ Frequency:5pF @ 1MHz
• Operating Temperature:-40°C ~ 85°C (TJ)
• Mounting Type:Surface Mount
• Package / Case:10-UFDFN Exposed Pad
• Supplier Device Package:10-DFN (2.6x2.6)
