DSPIC33CH256MP505-I/M4

Technical Details

• Series:Automotive, AEC-Q100, dsPIC™ 33CH, Functional Safety (FuSa)
• Package:Tube
• Part Status:Active
• Core Processor:dsPIC
• Core Size:16-Bit Dual-Core
• Speed:180MHz, 200MHz
• Connectivity:CANbus, I²C, IrDA, LINbus, SPI, UART/USART
• Peripherals:Brown-out Detect/Reset, DMA, Motor Control PWM, POR, PWM, QEI, WDT
• Number of I/O:39
• Program Memory Size:328kB (328k x 8)

• Program Memory Type:FLASH, PRAM
• EEPROM Size:-
• RAM Size:48K x 8
• Voltage - Supply (Vcc/Vdd):3V ~ 3.6V
• Data Converters:A/D 31x12b; D/A 4x12b
• Oscillator Type:Internal
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:48-UFQFN Exposed Pad
• Supplier Device Package:48-UQFN (6x6)
