MC9S08SH16CTG
NXP Semiconductors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC MCU 8BIT 16KB FLASH 16TSSOP
- CategoryEmbedded - Microcontrollers
- Datasheet MC9S08SH16CTG Datasheet
-
ECAD Model
- Share
In Stock: 1,632
Can ship immediately
Pricing:
- 1$5.57
- 10$5.05288
- 96$4.80277
- 192$4.22646
- 576$3.66931
- 1,056$3.16982
Quote It
Technical Details
- Series:S08
- Package:Tube
- Part Status:Active
- Core Processor:S08
- Core Size:8-Bit
- Speed:40MHz
- Connectivity:I²C, LINbus, SCI, SPI
- Peripherals:LVD, POR, PWM, WDT
- Number of I/O:13
- Program Memory Size:16KB (16K x 8)
- Program Memory Type:FLASH
- EEPROM Size:-
- RAM Size:1K x 8
- Voltage - Supply (Vcc/Vdd):2.7V ~ 5.5V
- Data Converters:A/D 8x10b
- Oscillator Type:Internal
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:16-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package:16-TSSOP
