MC56F8002VWL
NXP Semiconductors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC MCU 16BIT 12KB FLASH 28SOIC
- CategoryEmbedded - Microcontrollers
- Datasheet MC56F8002VWL Datasheet
-
ECAD Model
- Share
In Stock: 363
Can ship immediately
Pricing:
- 1$6.65
- 10$5.96652
- 26$5.64063
- 104$4.88854
- 520$4.16153
- 1,014$3.50973
Quote It
Technical Details
- Series:56F8xxx
- Package:Tube
- Part Status:Active
- Core Processor:56800E
- Core Size:16-Bit
- Speed:32MHz
- Connectivity:I²C, LINbus, SCI, SPI
- Peripherals:LVD, POR, PWM, WDT
- Number of I/O:23
- Program Memory Size:12KB (6K x 16)
- Program Memory Type:FLASH
- EEPROM Size:-
- RAM Size:1K x 16
- Voltage - Supply (Vcc/Vdd):1.8V ~ 3.6V
- Data Converters:A/D 15x12b
- Oscillator Type:Internal
- Operating Temperature:-40°C ~ 105°C (TA)
- Mounting Type:Surface Mount
- Package / Case:28-SOIC (0.295", 7.50mm Width)
- Supplier Device Package:28-SOIC
