MC9S08SH8CFK
NXP Semiconductors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC MCU 8BIT 8KB FLASH 24QFN
- CategoryEmbedded - Microcontrollers
- Datasheet MC9S08SH8CFK Datasheet
-
ECAD Model
- Share
In Stock: 1,398
Can ship immediately
Pricing:
- 1$4.2
- 10$3.77207
- 25$3.56604
- 100$3.09057
- 500$2.63095
- 1,000$2.21887
Quote It
Technical Details
- Series:S08
- Package:Tray
- Part Status:Active
- Core Processor:S08
- Core Size:8-Bit
- Speed:40MHz
- Connectivity:I²C, LINbus, SCI, SPI
- Peripherals:LVD, POR, PWM, WDT
- Number of I/O:17
- Program Memory Size:8KB (8K x 8)
- Program Memory Type:FLASH
- EEPROM Size:-
- RAM Size:512 x 8
- Voltage - Supply (Vcc/Vdd):2.7V ~ 5.5V
- Data Converters:A/D 12x10b
- Oscillator Type:Internal
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:24-VFQFN Exposed Pad
- Supplier Device Package:24-QFN-EP (4x4)
