MC9S08DN16AMLF
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC MCU 8BIT 16KB FLASH 48LQFP
- CategoryEmbedded - Microcontrollers
- Datasheet MC9S08DN16AMLF Datasheet
-
ECAD Model
- Share
In Stock: 393
Can ship immediately
Pricing:
- 1$5.25
- 1,250$4.779
Quote It
Technical Details
- Series:S08
- Package:Bulk
- Part Status:Active
- Core Processor:S08
- Core Size:8-Bit
- Speed:40MHz
- Connectivity:I²C, LINbus, SCI, SPI
- Peripherals:LVD, POR, PWM, WDT
- Number of I/O:39
- Program Memory Size:16KB (16K x 8)
- Program Memory Type:FLASH
- EEPROM Size:512 x 8
- RAM Size:1K x 8
- Voltage - Supply (Vcc/Vdd):2.7V ~ 5.5V
- Data Converters:A/D 16x12b
- Oscillator Type:External
- Operating Temperature:-40°C ~ 125°C (TA)
- Mounting Type:Surface Mount
- Package / Case:48-LQFP
- Supplier Device Package:48-LQFP (7x7)
