PIC16F1503-I/P
Microchip Technology
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC MCU 8BIT 3.5KB FLASH 14DIP
- CategoryEmbedded - Microcontrollers
- Datasheet PIC16F1503-I/P Datasheet
-
ECAD Model
- Share
In Stock: 313
Can ship immediately
Pricing:
- 1$1.09
- 25$0.99014
- 100$0.89333
Quote It
Technical Details
- Series:PIC® 16F, Functional Safety (FuSa)
- Package:Tube
- Part Status:Active
- Core Processor:PIC
- Core Size:8-Bit
- Speed:20MHz
- Connectivity:I²C, SPI
- Peripherals:Brown-out Detect/Reset, POR, PWM, WDT
- Number of I/O:11
- Program Memory Size:3.5KB (2K x 14)
- Program Memory Type:FLASH
- EEPROM Size:-
- RAM Size:128 x 8
- Voltage - Supply (Vcc/Vdd):2.3V ~ 5.5V
- Data Converters:A/D 8x10b
- Oscillator Type:Internal
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Through Hole
- Package / Case:14-DIP (0.300", 7.62mm)
- Supplier Device Package:14-PDIP
